PDU-RT5002 Military Power Distribution Unit — Rack-Mount Rugged PDU

The PDU-RT5002 Military Power Distribution Unit is a 19-inch 4U rack solution developed by TEDEG Defence R&D for mission-critical power distribution. It serves command posts, military truck platforms, and fixed military sites by distributing energy from three sources (UPS, utility grid, generator) across ten protected outputs.

Unlike commercial PDUs, PDU-RT5002 combines military EMI/EMC compliance, environmental durability, and remote supervision in one enclosure. Integrators looking for a military power distribution unit get MIL-STD-461F/810G test coverage and series production in Türkiye.

The 10 × 25A AC/DC output configuration matches typical tactical truck architectures: eight to twelve critical loads plus two to four spare channels. Automatic source transfer (utility first, then generator) removes operator intervention during field scenarios.

MIL-STD-461F (CE102, CS101, CS114-116, RE102, RS103) ensures coexistence with onboard radar and radios; TEDEG developed a dedicated filter topology in its Ankara R&D lab. MIL-STD-810G environmental testing covers eleven methods including low pressure, low temperature, humidity, salt fog, vibration, and shock.

Ethernet-based monitoring, 100-entry logging, and granular fault modes accelerate field diagnostics. Breaker-based overcurrent and short-circuit protection isolates faults without collapsing the entire bus.

Technical specifications:

PDU-RT5002 acts as the central PDU on 6×6 air-defence trucks, feeding radar, consoles, and launcher subsystems concurrently. Mobile command containers use it for seamless UPS-to-generator transitions during extended missions.

The unit is equally suited to 24/7 fixed military facilities and maintenance depots requiring multi-source distribution.

• MIL-STD-461F — EMI/EMC: CE102, CS101, CS114, CS115, CS116, RE102, RS103 tests
• MIL-STD-810G — Environmental durability: low pressure, low temperature, contamination by fluids, solar radiation, rain, humidity, fungus, salt fog, sand and dust, vibration, shock (11 methods total)

TEDEG Defence moved PDU-RT5002 from concept to series production with an integrated hardware and software team. Standard lead time is 8–12 weeks, reducing programme risk versus 20+ week cycles common among global suppliers.

Domestic manufacturing offers NATO buyers supply-chain flexibility while preserving MIL-STD qualification. Customer variants (channel count, voltage, connectors) extend through modular design without lengthy re-qualification.

Validated by Turkish Defence Primes: The system is supplied as an approved vendor of ASELSAN, Roketsan and the Turkish Ministry of National Defence (MSB). Field-proven service record in tactical truck and fixed-site programmes within the Turkish Armed Forces inventory. NATO supplier registration (NCAGE): TM885. ITAR-Free — no US-origin controlled content.

Production Maturity: The PDU-RT5002 is delivered at day-one production maturity — field-proven topology, certified component sourcing from recognised suppliers, and rapid serial-production capability. Our team carries more than a decade of R&D and production experience in the defence power-distribution segment.
