Purpose

The main purpose of the T-Light Mobile Lighting Tower is to deliver continuous, high-intensity, and safe illumination in mission environments.
It is designed to enhance situational awareness, operational safety, and energy efficiency in both military operations and civil emergency scenarios.

Developed with TEDEG engineering expertise, the system features a built-in air compressor and motorized mast that enable automatic deployment and retraction without the need for external equipment.
Its roof-mounted configuration allows vehicle integration without occupying interior volume.

T-Light is the ideal solution for night operations, disaster response missions, radar maintenance activities, and surveillance operations.

Applications

The T-Light Mobile Lighting Tower offers wide usability across military, civil, and industrial platforms.

1️⃣ Military Applications

• Armored vehicles, radar systems, tactical mission vehicles, and command-control units
• Lighting for night operations, base camps, and maintenance areas
• Field exercises and temporary deployment zones requiring mobile illumination

2️⃣ Disaster & Emergency Response Systems

• Field lighting for AFAD, fire and rescue vehicles
• Emergency illumination during power outages
• Mobile medical, search-and-rescue, and shelter units

3️⃣ Industrial & Maintenance Operations

• Factories, testing facilities, and maintenance workshops
• Mobile service and repair vehicles
• Construction, energy, and infrastructure works requiring night visibility

4️⃣ Naval & Air Platforms

• On-deck maintenance, radar, and antenna systems
• Airfield apron lighting and ground support operations

This versatility makes T-Light a platform-independent, multi-mission illumination system.

Key Features

1️⃣ Powerful and Efficient Illumination

• Total light output: 112,000 lumens
• 2 × 600 W LED modules for high brightness
• Low power consumption, long LED lifespan (> 50,000 hours)
• 360° horizontal / 330° vertical rotation capability

2️⃣ Mechanical Durability

• Telescopic elevation up to 3.5 m
• Wind resistance: 66 km/h
• Compliant with MIL-STD-810G for shock, vibration, and humidity
• Aluminum 6000-series corrosion-resistant body

3️⃣ Intelligent Control Functions

• RS-485 (Modbus RTU) and Pelco-D/P protocol support
• Wireless control option
• Position feedback and auto-park sensors
• Integrated operation time counter

4️⃣ Safety and Protection

• IP67 protection rating
• Automatic shutdown and safe-stop mechanism
• Low-voltage and reverse-polarity protection

5️⃣ Easy Integration

• Roof-mounted installation (no internal space required)
• Power input options: DC 12 V / 24 V or AC 220 V
• MIL-DTL-38999 military-grade connectors

Operating Principle

The T-Light Mobile Lighting Tower operates through an integrated electromechanical mast system and intelligent control unit.
Once activated—via wired or wireless remote—the built-in air compressor raises the telescopic mast to the desired height.
Simultaneously, the LED modules power up and adjust to the pre-set pan/tilt positions.

Through RS-485 / Pelco-D communication protocol, the operator can:

• Control light intensity
• Manage pan and tilt movement
• Adjust mast height
• Monitor system status and diagnostics

At the end of the operation, the tower automatically retracts to its park position, completing a fully automated, maintenance-free cycle.

Main Components

1️⃣ Telescopic Mast Unit:
Gear-rack and pneumatic structure extending up to 3.5 m, made of aluminum alloy.

2️⃣ LED Lighting Modules:
Dual 600 W high-power LED projectors providing wide, uniform light distribution.

3️⃣ Motorized Pan/Tilt Mechanism:
Enables 360° horizontal and 330° vertical motion for precise illumination control.

4️⃣ Control Unit:
Microcontroller-based system with RS-485 interface, supporting both wired and wireless operation.

5️⃣ Connectors:
MIL-DTL-38999 military connectors ensuring high durability and EMI protection.

6️⃣ Compressor and Power Unit:
Integrated air compressor for mast elevation; operates on DC 12/24 V or AC 220 V power.

Test Standards and Compliance

Function and Benefits

The T-Light Mobile Lighting Tower is designed to provide visual awareness, operational safety, and uninterrupted illumination in field missions.
Its compact structure, powerful LED output, and intelligent automation reduce operator workload while maximizing efficiency.

With T-Light, users gain:

• Energy efficiency in the field
• Improved operational safety in low-visibility environments
• Long-term performance under harsh conditions
• Space-saving integration on vehicle platforms

Conclusion

The T-Light Mobile Lighting Tower is a product of TEDEG Defense’s military-grade engineering and mission-proven reliability.
With its high-power lighting capacity, IP67 protection, intelligent control architecture, and compliance with MIL-STD-810G / MIL-STD-461F,
T-Light provides continuous illumination for every mission scenario — from military platforms to disaster response operations.
