Purpose

The purpose of this product is to convert a specific input voltage and frequency into a different output voltage and frequency. This is particularly important for regions with different energy standards or for devices with specific energy requirements.

Applications

• Military Ships: For stabilizing power systems and operating various devices.
• Industrial Facilities: To provide the specific voltages and frequencies needed for production machinery.
• Airports: To meet the energy needs of aircraft and ground support equipment.

Types

• Fixed Output Frequency Converters: Provide a specific output frequency.
• Adjustable Output Frequency Converters: Allow the output frequency to be adjusted according to user requirements.

Features

• High Efficiency: Minimizes energy losses.
• Wide Input Voltage Range: Can be powered from various energy sources.
• Robust Construction: Ensures reliable performance under harsh conditions.
• Protection Features: Includes advanced safety features such as overload, short circuit, and temperature protection.
• Modular Design: Facilitates easy maintenance and repair.
• Digital Communication and Fault Reporting: The product can send all faults, warnings, and status information to the user and main control unit via Ethernet and RS-482 communication infrastructure. It has OLED screens for digitally displaying faults and information.
• Multiple Output and Frequency Support: The system is the first and only product that can convert both 400 Hz and 60 Hz. It can smartly switch power to 7 different outputs with 115 VAC 400 Hz and 115 VAC 60 Hz.

Keywords and LSI Keywords

• Keywords: AC-AC frequency converter, static frequency converter, power converter, transformer, high efficiency, industrial power solutions, military power systems.
• LSI Keywords: Voltage converter, frequency stabilizer, energy conversion device, power management system, electrical protection, modular power solution.

How It Works

The AC-AC frequency converter transformer first converts the input AC voltage to DC using an AC-DC converter, and then converts the DC voltage to the desired AC voltage and frequency using a DC-AC converter. High-frequency electronic circuits and control algorithms are employed to ensure high efficiency and precision throughout this process.

Components

• Input Filters: Regulate the input voltage and prevent potential interference.
• AC-DC Converter: Converts input AC voltage to DC.
• DC-AC Converter: Converts DC voltage to the desired AC voltage and frequency.
• Control Unit: Manages the conversion processes and controls output parameters.
• Output Filters: Regulate the output voltage and provide a pure sine wave.
• OLED Screens: Display digital fault and information notifications.
• Transformer and Inductors: Create magnetic fields for energy transmission during conversion processes.

Compliance with Test Standards

• EMC Compliance: Meets electromagnetic compatibility tests.
• Safety Tests: Has passed overload, short circuit, and temperature protection tests.
• Military Standards: Tested in accordance with military standards such as MIL-STD-810G and MIL-STD-461F.

Functionality

This product safely and efficiently converts input voltage and frequency to the desired values, ensuring the smooth and reliable operation of devices with different energy requirements. It is especially useful for standardizing energy requirements across different regions and in specialized applications.
